N2001 Propane regulator converter silicone 150HP engine industrial forklift

N2001 Propane regulator converter silicone 150HP engine industrial forklift

Regular price
$270.00 USD
Sale price
$270.00 USD
Regular price
Sold out
Unit price
per
Shipping calculated at checkout.

Brand Name: CENTURY
Model #: N2001
Condition: New

The N-2001 regulator is an LPG liquid withdrawal high pressure regulator. This regulator provides excellent fuel delivery with liquid-cooled engines. With the N-2001's improved vaporization characteristics, liquid propane enters the regulator and then is vaporized using heat from the engine's coolant. LP-Gas is fed to the underside of the diaphragm through a small orifice. A pilot valve moves a lever in the regulator and a larger orifice is opened up and pressure under the diaphragm is lowered. This pressure differential allows the diaphragm to push the main valve to open as long as the engine vacuum maintains the pilot valve pin in the open position. The instant the engine stops the pilot valve is closed (spring assisted) stopping fuel flow.

Forklift interchange part numbers:
A343007
000026605
37962
8001390078

Specifications
Fuel Type:                    LPG Liquid/Vapor
Certified Systems:            Closed-Loop
Mounting Position:            Vertical or Horizontal
Diaphragm Material:    Silicone
HP:                                    150 HP
Inlet Pressure, (Max)         312 psi (21.51 Bar)
