D Mart Parts
Heavy Duty Main Contactor Solenoid SW180 24 Volts 200 Amps Golf Car Electric
Heavy Duty Main Contactor Solenoid SW180 24 Volts 200 Amps Golf Car Electric
Regular price
$94.00 CAD
Regular price
Sale price
$94.00 CAD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
GOLF CART 24 VOLT HIGH 200 AMPS UNIVERSAL SOLENOID CONTACTOR SW180B-48 Aftermarkt Product High Quality Tested
24 Volts
Rated Current - 200 Amps
Single Pole, Single Throw, Normally Open
Magnetic Blowouts
the SW180 series of contactors has been designed for direct current loads, particularly motors as used on electric vehicles such as industrial trucks, airport tractors, and such like. They have double breaking main contacts with silver alloy contact tips, which are weld resistant, hard wearing and have excellent conductivity. Rated Current - 200 Amps. Single Pole, Single Throw, Normally Open. Magnetic Blowouts. Coil Power - 11 to 14W. Rated Voltage of Contact Circuit - 6 to 80 Volts DC. Dielectric Voltage Strength - 50Hz 1000V AC 1min. Current Volt Drop of Main Contact at 100A - Not above 80mV. Operating time, Contact Makes & Contact Brakes - >30ms. Mechanical Life - 100 thousand times. Electric Life - 20 thousand times.
24 Volts
Rated Current - 200 Amps
Single Pole, Single Throw, Normally Open
Magnetic Blowouts
the SW180 series of contactors has been designed for direct current loads, particularly motors as used on electric vehicles such as industrial trucks, airport tractors, and such like. They have double breaking main contacts with silver alloy contact tips, which are weld resistant, hard wearing and have excellent conductivity. Rated Current - 200 Amps. Single Pole, Single Throw, Normally Open. Magnetic Blowouts. Coil Power - 11 to 14W. Rated Voltage of Contact Circuit - 6 to 80 Volts DC. Dielectric Voltage Strength - 50Hz 1000V AC 1min. Current Volt Drop of Main Contact at 100A - Not above 80mV. Operating time, Contact Makes & Contact Brakes - >30ms. Mechanical Life - 100 thousand times. Electric Life - 20 thousand times.
